EUREMELT 3413
Harmonization Code : 3214.10.00 | Putty and other mastics | Resin cements, caulking compounds and other mastics
Main features
- 2.8 to 4.0 Pa s Melt Viscosity
- Flexibility to -35 deg C
- 23 kV/mm Dielectric Strength
Product Description
EUREMELT 3413 is a black copolyamide thermoplastic hot-melt adhesive supplied as granules for low-pressure injection molding around electrical and electronic devices. It combines a specified softening point of 150–160 °C with a specified melt-viscosity range of 2.8–4.0 Pa·s at 210 °C. The material is applied at 180–220 °C and provides flexible molded encapsulation, including low-temperature flexibility to −35 °C. It adheres to PVC and other plastics and is used where low-pressure molding must form a protective molded body around components, connectors, wiring, or related assemblies. Typical electrical properties include 23 kV/mm dielectric strength, 3 × 1012 Ω·cm specific resistance, and CTI 600.
Key features
- Low-pressure molding grade: Thermoplastic copolyamide hot melt for casting electrical devices by low-pressure injection molding.
- Controlled melt processing: Specified melt viscosity of 2.8–4.0 Pa·s at 210 °C and an application-temperature range of 180–220 °C.
- Low-temperature flexibility: Typical flexibility to −35 °C according to ASTM D 3111.
- Electrical insulation data: Typical dielectric strength of 23 kV/mm, specific resistance of 3 × 1012 Ω·cm, and CTI 600.
- Plastic adhesion: Documented adhesion to PVC and other plastics.
Applications / Suitable for
- Low-pressure molding and encapsulation of electrical devices
- Connectors, cable assemblies, and wire-harness components
- Printed circuit assemblies, sensors, coils, relays, and related electronic components
TDS, SDS & Technical Documents
Technical Specifications
Electrical Properties
Additional Information
EUREMELT 3413
EUREMELT 3413 Black is a granulated copolyamide thermoplastic hot melt for low-pressure injection molding around electrical and electronic devices. Its controlled melt viscosity, flexible molded state, plastic adhesion, and electrical insulation data support evaluation for connectors, wiring assemblies, sensors, and related encapsulated components.
EUREMELT 3413 Black is supplied as black granules for melt processing.
As-supplied and melt properties
Specified values are guaranteed key data. Other listed values are typical and provided for product evaluation.
| Property | Value | Unit | Method / condition |
|---|---|---|---|
| As-supplied form | Granulate | — | Black |
| Amine value | ≤ 3 | mg KOH/g | ISO 9702; specified |
| Acid value | ≤ 10 | mg KOH/g | ISO 2114; specified |
| Softening point R+B | 150–160 | °C | ISO 4625; specified |
| Melt viscosity | 2.8–4.0 | Pa·s | ISO 2884 at 210 °C; specified |
| Melt viscosity | 4 | Pa·s | ISO 2884 at 200 °C; typical |
Melt, inject, cool, and demold
The granulated material is thermally melted and injected around the electrical or electronic assembly using a low-pressure molding process. EUREMELT 3413 does not require reactive mixing or chemical cure; the molded part develops through cooling after injection.
Insert an approved process visual showing the low-pressure molding sequence for an electrical assembly.
Store EUREMELT 3413 Black in a dry place, preferably in the sealed original packaging, between 2 and 40 °C and away from direct sunlight. The stated shelf life is two years; refer to the expiry date on the original container.
Final material properties
Values in this section are typical unless otherwise indicated. They are not guaranteed design specifications.
| Property | Value | Unit | Method / condition |
|---|---|---|---|
| Shore hardness | 86 A / 28 D | Shore | DIN ISO 7619 at 23 °C |
| Low-temperature flexibility | −35 | °C | ASTM D 3111 |
| Tensile strength | ≥ 4 | N/mm² | DIN EN ISO 527 at 23 °C |
| Elongation at tensile strength | ≥ 250 | % | DIN EN ISO 527 at 23 °C |
| Dielectric constant | 3.5 | — | 1 MHz |
| Specific resistance | 3 × 1012 | Ω·cm | 24 °C |
| Dielectric strength | 23 | kV/mm | Typical |
| Tracking resistance | CTI 600 | — | Test solution A |
| Water absorption | 0.7 / 1.5 / 2.35 / 2.75 | % | DIN EN ISO 62 at 23 °C after 24 h / 4 d / 14 d / 28 d |
Low-pressure molding applications
EUREMELT 3413 is positioned as a standard, broadly applicable grade for low-pressure molding. Final suitability depends on the component design, materials, molding conditions, and end-use requirements.
