ARALDITE GY6010
Harmonization Code : 3910.00.00.90 | Silicones in Primary Forms; Others
Main features
- Medium-Viscosity Liquid Processing
- Multiple Hardener Cure Options
- Versatile Resin Formulation Base
Product Description
ARALDITE GY 6010 Epoxy Resin is a medium-viscosity, unmodified liquid bisphenol-A epoxy resin for room-temperature and heat-cured systems. Its typical as-supplied profile includes 11,000 to 13,000 mPa s viscosity at 25 deg C, an epoxy equivalent of 182 to 192 g/eq, and density of 1.15 to 1.18 g/cm^3. The resin can be cured with multiple hardener types and formulated with compatible fillers, diluents, and accelerators. This versatility supports coatings, matrix-resin applications, electrical systems, adhesives, and civil-engineering work. Processing and final performance depend on the selected hardener, ratio, and cure schedule, so formulation data remain tied to the stated combination and test conditions.
Key features
- Medium-viscosity liquid handling: Typical viscosity is 11,000 to 13,000 mPa s at 25 deg C.
- Flexible cure formulation: The resin can be combined with multiple hardener types for room-temperature or heat-cured systems.
- Compatible formulation base: Documented compatibility includes many fillers, diluents, and accelerators.
Applications
Coatings, matrix resins, electrical systems, adhesives, and civil-engineering formulations.
TDS, SDS & Technical Documents
Technical Specifications
General Properties
Physical Properties
Additional Information
As-supplied / before-processing properties
Typical ARALDITE GY 6010 resin values from the exact-grade technical data sheet.
| Property | Value | Unit | Method / condition |
|---|---|---|---|
| Appearance | Clear, no contamination | - | Visual; typical |
| Color | 1 maximum | Gardner | Typical |
| Epoxy value | 5.2 to 5.5 | eq/kg | Typical |
| Epoxy equivalent | 182 to 192 | g/eq | Typical |
| Viscosity | 11,000 to 13,000 | mPa s (cP) | 25 deg C; typical |
| Density | 1.15 to 1.18 (9.6 to 9.8) | g/cm^3 (lb/gal) | 25 deg C; typical |
| Flash point | 254 (490) | deg C (deg F) | Closed cup; typical |
After-processing / final-state properties
Values apply only to 100 parts by weight ARALDITE GY 6010 with 50 parts ARADUR 2964. Cure and conditioning are preserved for each result.
| Property | Value | Unit | Method / condition |
|---|---|---|---|
| Transparency | Clear | - | GY 6010/ARADUR 2964 formulation |
| Surface appearance | Smooth, glossy | - | GY 6010/ARADUR 2964 formulation |
| Exudation | None | - | GY 6010/ARADUR 2964 formulation |
| Impact test | 70 | in-lb | After 2 months at 20 deg C and at 60 deg C |
| Mandrel test | 180 at 20 deg C; 60 at 60 deg C | deg | 15 mm mandrel; after 2 months |
| Adhesion after boiling-water exposure | Unchanged | - | Sandblasted mild-steel sheet; 6 hours at 96 deg C |
